The Main Menu General Information
NFS-3030 Operating P/N 51344:C 11/4/03 15
Figure 1.5 Main Menu Screen
Soft Keys
Pressing the soft keys brings the user to the screens described below.
1.7.1 Event Counts Display
Pressing the soft key to the left of the Event Counts Display message on the Main Menu
brings up the Event Counts screen. This screen will automatically display if an off-normal event
requiring acknowledgement occurs, unless the panel is in programming mode. Fire alarm events
will display even in programming mode.
Lines six and seven display current counts of off-normal events in six categories. The counts
include both acknowledged and unacknowledged events.
Figure 1.6 Events Count Display Screen
Soft Keys
ACKNOWLEDGE FIRE ALARM - Press this key to acknowledge an event. The command will read
ACKNOWLEDGE FIRE ALARM if the event is a fire alarm. It will read ACKNOWLEDGE if the event
is any other type. The command will not display if there are no events to acknowledge.
MORE INFORMATION - Press this key to go to the MORE INFORMATION screen, described in
Section 1.7.2 below. This button will not display if no off-normal events exist.
LAKEVIEW GENERAL HOSPITAL
SYSTEM NORMAL
11:58:45A WED JUN 25, 2003
EVENT COUNTS DISPLAY READ STATUS
PROGRAM/ALTER STATUS
MULTIPLE EVENT LIST PRINTER FUNCTIONS
HISTORY DISPLAY BACK
FIRE ALARM
ELEVATOR LOBBY EAST WING
FIFTH FLOOR Z005 SMOKE(PHOTO)
11:57:45A WED JUN 25, 2003 L03D052
EVENT COUNTS
FIRE ALARMS:001 PREALARM:000 TROUBLE:000
SUPERVISORY:000 SECURITY:000 DISABLE:000
11:58:45A WED JUN 25, 2003
ACKNOWLEDGE FIRE ALARM SIGNAL SILENCE
MORE INFORMATION SYSTEM RESET
PROGRAM/ALTER STATUS BACK
