Alphabetical List Software Type ID Codes
NFS-3030 Operating P/N 51344:C 11/4/03 59
Appendix A Software Type ID Codes
Alphabetical List
The following chart lists NFS-3030 Type ID codes in alphabetical order. These codes are assigned
during programming based on the types and functions of the devices they are assigned. The codes
appear in point message formats.
Software Type ID Code Device
ABORT SWITCH Monitor that provides an abort function for a releasing zone through connection to a UL-listed
abort station)
ACCESS MONTR Monitor for building access
ACK SWITCH Monitor used to silence panel sounder, and to give an acknowledge message on the panel
display
AIR REF FSL-751 detector used to monitor air quality entering a protected area
ALARMS PEND Control module/panel circuit or NAC for output that will activate upon receipt of an alarm
condition, and remain in the alarm state until all alarms have been acknowledged.
Programmed for switch inhibit
ALLCALL PAGE Monitor used for emulation of AMG-1 All-call switch, activating all speaker circuits
AREA MONITOR Monitor for building access
AUDIBLE CKT Control module/panel circuit relay used on audible circuit NAC
AUDIO SYSTEM Monitor for audio equipment
BELL CIRCUIT Control module used with NAC with bells
blank Operates as CONTROL with no Type ID label
CONTROL Control module used with NAC
CONTROL NAC Control module/ Panel circuit relay or NAC
DRILL SWITCH Monitor used for activation that emulates panel Drill switch, activating silenceable fire outputs
EQUIP MONITR Monitor used for recording access to equipment
EVACUATE SWITCH Monitor used for activation that emulates panel Drill switch, activating silenceable fire outputs
FIRE CONTROL Monitors non-fire activations
FORM C RESET Control module used to interrupt 24V power to four-wire conventional detectors for 30 seconds
upon reset. Used in conjunction with a monitor module with a conventional detector Type ID
GEN ALARM Control module, XPC-8 circuit, or XP5-C (NAC mode) configured as a Municipal Box
Transmitter for NFPA 72 Auxiliary Fire Alarm Systems applications (MBT-1 required). This
Type ID can also be used for general alarm activation. It is programmed as “switch inhibit”.
GEN PEND Control module, XPC-8 circuit, or XP5-C (NAC mode) that will activate upon receipt of an alarm
and/or trouble condition, and remain in the ON state until all events have been acknowledged
GEN SUPERVIS Control module, XPC-8, or XP5-C (NAC mode) activated under any supervisory condition
(includes sprinkler type). It is programmed as “switch inhibit”
GEN TROUBLE Control module, XPC-8, or XP5-C (NAC mode) activated under any System Trouble condition.
It is programmed as “switch inhibit”
HEAT Adjustable threshold heat detector
HEAT+ Adjustable threshold heat detector with a low temperature warning.
HEAT(FIXED) Intelligent 135ºF thermal sensor detector
HEAT(ROR) 15ºF per minute rate-of-rise detector
HEAT DETECT Monitor for conventional heat detector
HORN CIRCUIT Control module/panel circuit relay module used with NAC with horns
INST RELEASE Control module used with NAC. Always non-silenceable and switch-inhibited
ISOLATED NAC Supervised NAC for notification appliance, used with audio isolators. Activates even if there is
a short on its NAC circuit. Canada installations only.
ISOLATED SPK Supervised NAC for speaker circuit, used with audio isolators. Activates even if there is a short
on its audio circuit. Canada installations only.
LATCH SUPERV Indicates latching supervisory condition
MAN RELEASE Monitor module that provides manual release for a releasing zone through connection to a UL-
listed pull station
MAN REL DELAY Monitor module that provides manual release with a 10 second delay for a releasing zone
through connection to a UL-listed pull station
MONITOR Alarm-monitoring device
NON FIRE Monitors non fire activations
NONRESET CTL Output unaffected by “System Reset” command
PAS INHIBIT Monitor used to inhibit Positive Alarm Sequence (PAS)
