Printer Functions Screen Printing Reports
NFS-3030 Operating P/N 51344:C 11/4/03 51
Section 5 Printing Reports
A variety of reports can be generated and printed from the NFS-3030. Reports listing all event,
alarm, trouble, supervisory, or security history can be generated from the history screens in Section
4, "Viewing and Printing History Information". The following section describes how to print
programming, Walk Test, and active point information.
Note: Report formats are shown below as printed by an 80-column printer. When these reports are
printed on a Keltron, which is a 40-column printer, the formats are the same except they are
displayed on two lines instead of one.
5.1 Printer Functions Screen
The following screen displays when the Printer Functions soft key is pressed at the Main
Menu. This key will appear only if a printer has been selected through programming.
Figure 5.1 Printer Functions Screen
Soft Keys
PROGRAMMING: Press this soft key to display the Print Programming Menu screen.
ACTIVE POINTS: Press this soft key to display the Active Points Menu screen.
WALK TEST: Press this soft key to print point activations for the last Walk Test performed. The
report looks like this:
DETECT MAINTENANCE REPORT: Press this soft key to print a list from the printer connected
to the control panel that contains the detector maintenance status for each installed addressable
LAKEVIEW GENERAL HOSPITAL
SYSTEM NORMAL
10:22:34A WED JUN 25, 2003
PRINTER FUNCTIONS
PROGRAMMING
ACTIVE POINTS INSTALLED POINTS
WALK TEST
DETECTOR MAINTENANCE REPORT BACK
******WALK TEST RESULTS*********************************************************
TEST NO ANSWER DETECTOR 73
Z003 SMOKE(ION) 02:54:04P WED JUN 11,2003 L01D073
TEST FIRE ALARM ROOM 101 1ST FLOOR
Z001 HEAT(ANALOG) 02:54:31P WED JUN 11,2003 L01D003
TEST FIRE ALARM ROOM 221 2ND FLOOR
Z001 SECURITY 02:54:59P WED JUN 11,2003 L01M004
TEST ACTIVE LAB 3RD FLOOR
Z004 CONTROL 02:55:09P WED JUN 11,2003 L01M005
