44951501TH Rev.2
5-26
Oki Data CONFIDENTIAL
5. MAINTENANCE MENUS
5.4 Setup after part replacement
Note: When removing or writing information from/into the EEPROM by using
Maintenance Utility, use the procedure shown below to place the printer to
the Forced ONLINE mode before accessing the EEPROM. Even in the forced
ONLINE mode, the printer provides an error indication when having an error.
1. When turning on the printer, press and hold down
, and the OK button
in combination until STATUS MODE appears on the operator panel.
2. The printer displays ONLINE when operating properly, and provides an
error indication when having an error, where the printer is internally online,
being ready to communicate.
The following describes the adjustments required after part replacement:
Replaced part Adjustment
LED head Requires no adjustments.
Drum cartridge (yellow, magenta,
cyan or black)
Requires no adjustments.
Fuser unit Requires no adjustments.
Belt unit Requires no adjustments.
PU board Copying information stored in the EEPROM,
which requires utility software.
CU board Replacement of the EEPROM, which uses
EEPROM intended for use in a user printer.
Note: See section 4.2.6, LED assembly for compatibility of LEDs with the LEDs to replace
with them, and identification of those LEDs.
5.4.1 Notes on CU/PU board replacement
1. When the EEPROM on a board to remove can be accessed (when SERVICE
CALL 104 [Engine EEPROM Error] or 40 [EEPROM Error] is not displayed):
(1) Remove information from the EEPROM in the PU block, and setting information
from the EEPROM in the CU block, of the board, and temporarily store them
onto an HDD of a computer, by using the board replacement function of
Maintenance Utility (Maintenance Utility Operating Manual, section 2.4.1.1.9
about board replacement functionality).
(2) By using the board replacement function, copy the information and setting
information into the EEPROM of a board to replace with.
(3) When only the information or setting information can be removed from the board
to replace, copy it into the EEPROM of the replacement board by using the board
replacement function. With the board replacement function, separately configure
the other information, which cannot be removed. Perform PU-block serial-
number setting (Maintenance Utility Operating Manual, section 2.4.1.1.9.5), and
make a change to the Shipping mode (Maintenance Utility Operating Manual,
section 2.4.1.1.9.6), in setting windows when the information cannot be removed.
Configure CU-block serial number information (Maintenance Utility Operating
Manual, section 2.4.1.1.9.4) when the setting information cannot be removed.
To Next Page
