Menu functions > 26
PCL
EMULATION
This menu controls settings effective when the printer is operating in PCL emulation mode.
ITEMS SETTINGS EXPLANATION
FONT SOURCE RESIDENT /
RESIDENT2
DOWNLOADE
D
Specifies the location of the PCL default font. Normally this will be
INTERNAL unless additional fonts are installed in the expansion ROM slot or
additional fonts have been downloaded to RAM as permanent fonts.
FONT No. I0/ C001 /
S001
Sets the current default font number from the currently selected source,
which could be internal (I), ROM slot (C) or downloaded (S).
FONT PITCH 0.44CP!~
10.00CPI~
99.99CPI
Sets the width of the PCL default font in characters/inch (CPI).
Default font is the fixed-pitch, scalable font. The value is displayed to the
second decimal place
Displayed only when the font selected in Font No. is fixed-spacing, scalable
font.
SYMBOL SET PC-8
(Default
Symbol Set
only shown)
PCL symbol set. If the font source and number are changed to one which
does not support the selected symbol set, this must be changed to an
available symbol set for that font.
A4 PRINT
WIDTH
78 COLUMN
80 COLUMN
Sets the number of columns subject to Auto LF with A4 paper in PCL. This is
the value when Auto CR/LF Mode is set to OFF with the 10CPI character.
WHITE PAGE
SKIP
OFF / ON Selects whether blank pages are printed or not.
CR FUNCTION CR / CR+LF Selects whether a received carriage return character (0Dh) also causes a
line feed.
LF FUNCTION LF / LF+CR Selects whether a received line feed character (0Ah) also causes a carriage
return.
PRINT
MARGIN
NORMAL
1/5 INCH
1/6 INCH
Sets the non-printable page area. NORMAL is PCL compatible.
TRUE BLACK OFF / ON Selects whether black image data is printed using black toner (ON) or
100% CMY (OFF). (Valid in PCL emulation mode only.)
PEN WIDTH
ADJUST
ON/OFF Set to ON when minimum width specified, to stretch a one dot line and
eliminate gaps.
TRAY ID# MP TRAY
1-2-59
