- 84 -
3. Basic Operations
Names of Component
s
The chapter describes th
e name of each component.
•
Front View
•R
e
a
r
V
i
e
w
•
Inside of the machine
Front Vi
ew
Symbol
Name
a
Auto document feeder (ADF)
b
Document tray
c
Scanner unit
d
Operator panel
Basic Operations on the
Operator Panel
eU
S
B
p
o
r
t
f
MP tray (Multipurp
ose tray)
g
Open button
h
Paper supporter
i
Envelope lever (Use this when print
ing on envelopes. For instruction
s, refer to the Advanced
Manual.)
83
85
