- 85 -
3. Basic Operations
Symbol
Name
j
Document glass
k
Document glass cover
l
Wireless LAN module co
ver
Symbol
Name
m
Output tray
n
Tray 1
Rear View
Symbol
Name
a
T
elephone connector (for conn
ectin
g an external telephone)
b
LINE connector
c
Rear output
tray
d
Power
connecto
r
e
Interface con
nector cover
f
Network interface con
nector
g
USB interface conn
ector
84
