Comparison of the CX-Simulator and SYSMAC CS/CJ–series PLCs Section 1-7
19
Item CS/CJ-series PLC CX-Simulator
I/O Area CIO 0000 to CIO 0319 Not allocated actually even if the
unit is set.
Special
I/O Unit
Area
CIO 2000 to CIO 2959 Only Serial Communications Units
and Network Communications
Units are allocated.
DeviceNet
Area and
SYSMAC
BUS Area
DeviceNet Area:
CIO 0050 to CIO 0099,
CIO 0350 to CIO 0399
SYSMAC BUS Area:
CIO 3000 to CIO 3049
PLC Link
Words
CIO 0247 to CIO 0250 and A442
Optical I/O
Unit and
I/O Termi-
nal Area
I/O Terminal Area:
CIO 3100 to CIO 3131
Not allocated actually even if the
unit is set.
Link Relay
Area (LR)
Link Area: CIO 1000 to CIO 1199 Same as CS/CJ-series PLC.
Data
Areas
CIO
Area
Work/
Internal
I/O area
Internal I/O Area:
CIO 1200 to CIO 1499
CIO 3800 to CIO 6143
Same as CS/CJ-series PLC.
Work Area (WR) Work Area: W000 to W511 Same as CS/CJ-series PLC.
Temporary Relay
Area
TR 00 to TR 15 Same as CS/CJ-series PLC.
Holding Relay
Area(HR)
H 000 to H 511 Same as CS/CJ-series PLC.
Auxiliary Relay
Area (AR)
Auxiliary Area: A 000 to A 959 Same as CS/CJ-series PLC.
(Refer to 9-3 I/O Memory Alloca-
tion for details.
DM Area DM Area
D00000 to D32767
D20000 to D29599 are used by Special I/O
Units, D30000 to D31599 are used by CPU Bus
Units, and D32000 to D32099 are used by Inner
Boards.
The Error Log is stored in A100 to A199 and the
PLC Setup is stored in the Parameter Area (not
a part of I/O Memory).
Same as CS/CJ-series PLC.
EM Area EM Area
E00000 to E32767 (13 banks max.)
The EM Area in the CS/CJ-series CPU Unit can
be accessed directly by most instructions.
Regular instructions can access data in the
current bank or any other bank.
Part of the EM Area can be converted for use
as a file memory.
Same as CS/CJ-series PLC.
Timer Area T0000 to T4095 Same as CS/CJ-series PLC.
Counter Area C0000 to C4095
(Timer and counter numbers are independent.)
Same as CS/CJ-series PLC.
Data Areas
Task Flag Area TK0 to TK31 Same as CS/CJ-series PLC.
