Omron E5EC User Manual

6 - 11
6 Parameters
E5@C Digital Temperature Controllers User’s Manual (H174)
6-3 Operation Level
6
This parameter measures the heater current from the CT input used for detecting heater burnout.
This parameter measures the heater current from the CT input used for detecting SSR short-circuits.
ct2
Heater Current 2 Value Monitor
HB and HS alarms must be supported (two CTs).
The HB ON/OFF parameter must be set to ON.
This parameter measures and displays the heater current value.
• Heater burnout is not detected if the ON time for the control output for heating is 100 ms
or less (30 ms or less if the control period is 0.1 or 0.2 s).
• ffff is displayed when 55.0 A is exceeded.
• If an alarm is output for the Heater Burnout Detection 2 parameter, the No. 1 display will
flash the Heater Current 2 Value Monitor parameter.
 Related Parameters
Heater Burnout Detection 1 (Adjustment Level): Page 6-22
Heater Burnout Detection 2 (Adjustment Level): Page 6-23
HB ON/OFF (Advanced Function Setting Level): Page 6-65
Error Display ct2: Page A-17
lcr1
Leakage Current 1 Monitor
HB and HS alarms must be supported.
The HS Alarm Use parameter must be set to ON.
The heater current is measured and the leakage current 1 monitor is displayed.
• The HS alarm is not detected if the OFF time for the control output for heating is 100 ms
or less (35 ms or less if the control period is 0.1 or 0.2 s).
• ffff is displayed when 55.0 A is exceeded.
• If an alarm is output for the HS Alarm 1 parameter, the No. 1 display will flash the
Leakage Current 1 Monitor parameter.
 Related Parameters
HS Alarm 1 (Adjustment Level): Page 6-24
HS Alarm 2 (Adjustment Level): Page 6-25
HS Alarm Use (Advanced Function Setting Level): Page 6-77
Error Display lcr1: Page A-17
000
Function
Monitor
Monitor range Unit
0.0 to 55.0 A
See
See
Function
Monitor
Monitor range Unit
0.0 to 55.0 A
See
See
