A Appendices
A - 28
E5@C Digital Temperature Controllers User’s Manual (H174)
A-6-3 Initial Setting Level
Parameters Characters Setting (monitor) value Display Default Unit
Input Type in-t Temperature
input
0: Pt100
1: Pt100
2: Pt100
3: JPt100
4: JPt100
5: K
6: K
7: J
8: J
9: T
10: T
11: E
12: L
13: U
14: U
15: N
16: R
17: S
18: B
19: W
20: PLII
21: 10 to 70°C
22: 60 to 120°C
23: 115 to 165°C
24: 140 to 260°C
5 None
Analog input 25: 4 to 20 mA
26: 0 to 20 mA
27: 1 to 5 V
28: 0 to 5 V
29: 0 to 10 V
30: 0 to 50 mV
*1
5 None
Scaling Upper Limit in-h Scaling lower limit + 1 to 9,999 100 None
Scaling Lower Limit in-l −1,999 to scaling upper limit −1 0 None
Decimal Point dp 0 to 3 0 None
Temperature Unit d-u °C, °F
c, f
°C None
SP Upper Limit sl-h Temperature input: SP lower limit + 1 to Input setting
range upper limit
1300 EU
Analog input: SP lower limit + 1 to scaling upper limit 100
SP Lower Limit sl-l Temperature input: Input setting range lower limit to
SP upper limit − 1
−200 EU
Analog input: Scaling lower limit to SP upper limit − 10
PID ON/OFF cntl ON/OFF 2-PID onof, pid ON/OFF None
Standard or
Heating/Cooling
s-hc Standard or heating/cooling stnd, h-c Standard None
ST st OFF, ON off, on ON None
Program Pattern ptrn OFF, STOP, CONT off, stop,
cont
OFF None
Control Period
(Heating)
cp 0.1, 0.2, 0.5, or 1 to 99 0.1, 0.2, 0.5, 1
to 99
Relay
output: 20
Voltage
output (for
driving
SSR): 2
Seconds
Control Period
(Cooling)
c-cp 0.1, 0.2, 0.5, or 1 to 99 0.1, 0.2, 0.5, 1
to 99
Relay
output: 20
Voltage
output (for
driving
SSR): 2
Seconds
Direct/Reverse
Operation
orev Reverse operation, direct operation or-r, or-d Reverse
operation
None
To Next Page
