7 Connecting to LSIS PLCs
NB-series Programmable Terminals Host Connection Manual (V108)
7-2 Communication Parameters and Cable Fabrication
7
7-2 Communication Parameters and
Cable Fabrication
Series CPU Link Module
COMM
Type
Parameter Cable
K120S K7M-DR10UE Port1 on CPU unit RS232 Refer to Section
7-3
Self-made cable
required
Port2 on CPU unit RS485
K7M-DR20U Port1 on CPU unit RS232
Port2 on CPU unit RS485
K200S K3P-07AS RS232 on the CPU unit RS232
XBC XBC-DN64H
XBC-DR32H
RS232 on the CPU unit RS232
Built-in RS-232C RS232
Built-in RS-485 RS485
XEC XEC-DN60SU Built-in RS-232C RS232
Built-in RS-485 RS485
