3-3
3 Connecting to Mitsubishi PLCs
NB-series Programmable Terminals Host Connection Manual (V108)
3-1 Serial Port and Ethernet
3
3-1-2 Ethernet
*1 This protocol supports Multiple Station No..
*2 This protocol does not support Multiple Station No..
MELSEC Q Q06HCPU RS232 on the CPU unit Mitsubishi Q06H
QJ71C24
QJ71C24-R2
QJ71C24N
QJ71C24N-R2
QJ71C24N-R4
Mitsubishi Q_QnA (Link Port)
Q00UJCPU RS232 on the CPU unit Mitsubishi Q_QnA (Link Port)
Q06UDHCPU RS232 on the CPU unit Mitsubishi Q Series (CPU Port)
MELSEC L L02CPU
L02CPU-P
L02SCPU-P
L06CPU
L06CPU-P
L26CPU
L26CPU-P
L26CPU-BT
L26CPU-PBT
LJ71C24
LJ71C24-R2
Mitsubishi Q_QnA (Link Port)
L02SCPU RS232C port on CPU Unit
LJ71C24
LJ71C24-R2
Mitsubishi Q_QnA (Link Port)
3-1-2 Ethernet
Series CPU Link Module Driver
FXCPU FX3U FX3U-ENET-L Mitsubishi FX Series Ethernet (TCP Slave)
MELSEC Q Q03UDE
Q04UDEH
Q06UDEH
Q10UDEH
Q13UDEH
Q20UDEH
Q26UDEH
Q50UDEH
Q100UDEH
Q03UDV
Q04UDV
Q06UDV
Q13UDV
Q26UDV
Ethernet Port on CPU Unit Mitsubishi QnA 3EBin Ethernet (TCP Slave)
Q00CPU
Q00JCPU
Q01CPU
Q02CPU
Q02HCPU
Q06HCPU
Q12HCPU
Q25HCPU
QJ71E71-100 Mitsubishi QJ71E71 EtherNet Slave
Series CPU
Link Module
(The products in ( ) are also needed)
Driver
