3-5
3 Connecting to Mitsubishi PLCs
NB-series Programmable Terminals Host Connection Manual (V108)
3-2 Communication Setting and Cable Connection
3
3-2-1 Serial Port
3-2 Communication Setting and Cable
Connection
3-2-1 Serial Port
Series CPU Link Module COMM Type Parameter Cable
FXCPU FX1S
FX1N
FX2N
RS422 on the CPU unit RS422 Refer to Section 3-3 Self-made cable
required
RS232 Module RS232
RS485 Module RS422
FX1NC
FX2NC
RS422 on the CPU unit RS422
RS485 Module RS422
FX2N-10GM
FX2N-20GM
RS422 on the CPU unit RS422
FX3G
FX3GC
RS422 on the CPU unit RS422
RS232 Module RS232
RS485 Module RS422
FX3UC
FX3U
FX3S
RS422 on the CPU unit RS422
RS232 Module RS422
RS485 Module RS422
MELSEC Q Q00JCPU
Q02CPU
Q02HCPU
Q12HCPU
Q25HCPU
Q06HCPU
Q00UJ CPU
Q06UDHCPU
RS232 on the CPU unit RS232
Q00JCPU
Q00CPU
Q01CPU
Q02CPU
Q02HCPU
Q12HCPU
Q25HCPU
Q06HCPU
QJ71C24
QJ71C24-R2
QJ71C24N
QJ71C24N-R2
RS232
QJ71C24
QJ71C24N
QJ71C24N-R4
RS422
MELSEC L L02SCPU RS232 on the CPU unit RS232
L02CPU
L02CPU-P
L02SCPU
L02SCPU-P
L06CPU
L06CPU-P
L26CPU
L26CPU-P
L26CPU-BT
L26CPU-PBT
LJ71C24
LJ71C24-R2
RS232
LJ71C24 RS422
