9 Connecting to Allen-Bradley (Rockwell) PLC
9-4
NB-series Programmable Terminals Host Connection Manual (V108)
9-2 Communication Parameters and
Cable Fabrication
9-2-1 Serial Port
Series CPU Link Module COMM Type Parameter Cable
MicroLogix MicroLogix 1500
(1764-LRP)
Channel 1 RS232C Refer to Section 9-3 Self-made cable
required
MicroLogix 1000
MicroLogix 1200
MicroLogix
1500(1764-LSP,
1764-LRP)
Channel 0
AIC +Advanced
Interface Converter
1761-NET-AIC
MicroLogix
1400(1766-
L32BWAA)
Channel 0
Channel 2
SLC500 SLC 5/03
SLC 5/04
SLC 5/05
Channel 0 RS232C
1770-KF3
2760-RB
1775-KA
5130-RM
1771-KGM
CompactLogix 1769-L20
1769-L30
1769-L31
1769-L32E
1769-L35E
Channel 0 RS232C
Channel 1
ControlLogix 1756-L61 CPU Direct RS232C
9-2-2 Ethernet
Series CPU Link Module COMM Type Parameter Cable
MicroLogix MicroLogix 1100
MicroLogix 1400
Ethernet port on CPU
Unit
- Refer to Section 9-3 Network Cable
MicroLogix 1000
MicroLogix 1200
MicroLogix 1400
MicroLogix 1500
Communication Module
1761-NET-ENI
-
