3 Connecting to Mitsubishi PLCs
3-2
NB-series Programmable Terminals Host Connection Manual (V108)
3-1 Serial Port and Ethernet
3-1-1 Serial Port
Series CPU
Link Module
(The products in ( ) are also needed)
Driver
FXCPU FX1S RS422 on the CPU unit Mitsubishi FX1S *2
FX2NC-485-ADP (FX1N-CNV-BD)
FX0N-485-ADP (FX1N-CNV-BD)
FX1N--BD
Mitsubishi FX1S *2
Mitsubishi FX-485ADP/485BD/232BD
(Multi-station) *1
FX1N RS422 on the CPU unit Mitsubishi FX1N/2N/3G *2
FX2NC-485-ADP (FX1N-CNV-BD)
FX0N-485-ADP (FX1N-CNV-BD)
FX1N--BD
Mitsubishi FX1N/2N/3G *2
Mitsubishi FX-485ADP/485BD/232BD
(Multi-station) *1
FX2N RS422 on the CPU unit Mitsubishi FX1N/2N/3G *2
FX2NC-485-ADP (FX1N-CNV-BD)
FX0N-485-ADP (FX1N-CNV-BD)
FX2N--BD
Mitsubishi FX1S *2
Mitsubishi FX-485ADP/485BD/232BD
(Multi-station) *1
FX1NC RS422 on the CPU unit Mitsubishi FX1N/2N/3G *2
FX2NC-485-ADP (FX1N-CNV-BD)
FX0N-485-ADP (FX1N-CNV-BD)
Mitsubishi FX1N/2N/3G *2
Mitsubishi FX-485ADP/485BD/232BD
(Multi-station)
FX2NC RS422 on the CPU unit Mitsubishi FX1N/2N/3G *2
FX2NC-485-ADP (FX1N-CNV-BD)
FX0N-485-ADP (FX1N-CNV-BD)
Mitsubishi FX1N/2N/3G *2
Mitsubishi FX-485ADP/485BD/232BD
(Multi-station)
FX2N-10GM
FX2N-20GM
RS422 on the CPU unit Mitsubishi FX2N_10GM/20GM
FX3U
FX3UC
FX3S
RS422 on the CPU unit Mitsubishi FX3U *2
FX3U--BD
FX3U-485-ADP (FX3U-CNV_BD)
Mitsubishi FX3U *2
Mitsubishi FX-485ADP/485BD/232BD
(Multi-station) *1
FX3G
FX3GC
RS422 on the CPU unit Mitsubishi FX1N/2N/3G *2
FX3G--BD
FX3U-485-ADP (FX3G-CNV-ADP)
Mitsubishi FX-485ADP/485BD/232BD
(Multi-station) *1
MELSEC Q Q00JCPU RS232 on the CPU unit Mitsubishi Q00J (CPU Port)
QJ71C24
QJ71C24-R2
QJ71C24N
QJ71C24N-R2
QJ71C24N-R4
Mitsubishi Q_QnA (Link Port)
Q00CPU
Q01CPU
QJ71C24
QJ71C24-R2
QJ71C24N
QJ71C24N-R2
QJ71C24N-R4
Mitsubishi Q_QnA (Link Port)
Q02CPU
Q02HCPU
Q12HCPU
Q25HCPU
RS232 on the CPU unit Mitsubishi Q Series (CPU Port)
QJ71C24
QJ71C24-R2
QJ71C24N
QJ71C24N-R2
QJ71C24N-R4
Mitsubishi Q_QnA (Link Port)
