Omron SYSDRIVE 3G3EV User Manual

6-2
6-1 Specifications of Main Unit
H Rating
Three
Model 3G3EV-
A2001M(-j) A2002M(-j) A2004M(-j) A2007M(-j) A2015M(-j)
Three
phase,
200 VAC
Power
supply
Rated
voltage and
frequency
Three-phase, 200 to 230 VAC, 50/60 Hz
Allowable
voltage
fluctuation
–15% to 10 %
Allowable
frequency
fluctuation
±5%
Heating value (W) 11.9 18.8 33.2 51.7 71.6
Weight (kg) 0.5 0.6 0.9 1.3 1.5
Single
Model 3G3EV-
AB001M(-j) AB002M(-j) AB004M(-j) AB007M(-j) AB015M(-j)
Single
phase/
Three
phase,
Power
supply
Rated
voltage and
frequency
Single-phase, 200 to 240 VAC, 50/60 Hz
Three-phase, 200 to 230 VAC, 50/60 Hz
200 VAC
Allowable
voltage
fluctuation
–15% to 10 %
Allowable
frequency
fluctuation
±5%
Heating value (W) 12.6 20.3 25.3 55.3 78.4
Weight (kg) 0.5 0.6 1.3 1.3 2.0
Maximum applicable motor
capacity (kW)
0.1 0.2 0.4 0.75 1.5
Output
specifi-
Rated output
capacity (kVA)
0.3 0.6 1.1 1.9 2.7
specifi-
cations
Rated output current
(A)
0.8 1.5 3.0 5.0 7.0
Rated output
voltage
Three-phase, 200 to 230 VAC
(Corresponds to the input voltage)
Maximum output
frequency
400 Hz (Parameter setting)
Cooling method Self-cooling
Specifications Chapter 6
