D Single/Three-phase 200-VAC Input Model
3G3EV
model
Output W H D W1 H1 Weight
(kg)
AB004M(-j)
0.4 kW
108 128 130 96 118
Approx.
1.3
AB007M(-j)
0.75 kW Approx.
1.3
AB007M(-j)
1.5 kW 130 170 118 Approx.
2.0
D Three-phase 400-VAC Input Model
3G3EV model Output W H D W1 H1 Weight
(kg)
A4002M(-j)
0.2 kW
108 128
92
96 118
Approx.
1.0
A4004M(-j)
0.4 kW 110 Approx.
1.0
A4007M(-j)
0.75 kW 140 Approx.
1.5
A4015M(-j)
1.5 kW 130 170 118 Approx.
2.0
3-1-2 Installation Conditions
H Installation Site
•Install the Inverter under the following conditions:
Ambient temperature for operation: –10°C to 50°C
Humidity: 90% RH or less (non-condensing)
•Install the Inverter in a clean location free from oil mist and dust. Alternatively, install it
in a totally enclosed panel that is completely shielded from suspended dust.
•When installing or operating the Inverter, always take special care so that metal pow-
der, oil, water, or other foreign matter do not get in the Inverter.
•Do not install the Inverter on inflammables such as wood.
H Direction of Installation
•Install the Inverter on a vertical surface so that the characters on the nameplate are
oriented upward.
