1-2
1-1 Items to be Checked when Unpacking
H Checking the Product
On delivery, always check that the delivered product is the SYSDRIVE 3G3EV Inverter
that you ordered.
Should you find any problems with the product, immediately contact your nearest local
sales representative.
D Checking the Nameplate
Inverter model
Input specifications
Output specifications
M
D Checking the Model
3G3EV-A2002M-E
Special Specifications
Specifications
Maximum applicable motor capacity
Voltage class
Installation type/Option
Series name: 3G3EV Series
Specifications
Blank Standard model
M Multi-function model
R SYSMAC BUS model
Maximum Applicable Motor
Capacity
001 0.1 kW
002 0.2 (0.37) kW
004 0.4 (0.55) kW
007 0.75 (1.1) kW
015 1.5 kW
Note The figures in parentheses indi-
cate capacities for 400-VAC class
models.
Getting Started Chapter 1
