1-3
Voltage Class
2 Three-phase 200-VAC input
B Single/Three-phase 200-VAC
input
4 Three-phase 400-VAC input
Installation Type/Option
A Panel mounting models
(IP10 min) or wall-mounting
closed models
P Option
Special Specification
-E English Models
-CUE UL/CUL and EC Directives
Models
Blank Japanese Models
D Checking for Damage
Check the overall appearance and check for damage or scratches resulting from trans-
portation.
H Checking Accessories
Note that this manual is the only accessory provided with the 3G3EV (Multi-function
Model). Set screws and other necessary parts must be prepared by customers.
1-2 Precautions
To ensure safe operation of the 3G3EV, note the following items:
H Always Hold the Heat Sink During Removal.
When moving the 3G3EV, always hold the heat sink (aluminum portion on the rear of the
Unit).
Heat sink
Getting Started Chapter 1
To Next Page
