23
En
Others
Rated Output Power (IEC)
2 ch k 60 W at 4 ohms, 20 Hz-20 kHz, 2 ch driven of
0.5% THD
2 ch k 76 W at 4 ohms, 1 kHz, 2 ch driven of 0.9% THD
2 ch k 30 W at 8 ohms, 20 Hz-20 kHz, 2 ch driven of
0.4% THD
2 ch k 52 W at 8 ohms, 1 kHz, 2 ch driven of 0.9% THD
Dynamic Power (*)
(*)IEC60268-Short-term maximum output power
260 W (3 ≠, Front)
220 W (4 ≠, Front)
130 W (8 ≠, Front)
Input Sensitivity and Impedance
200 mV/47 k≠ (LINE (RCA))
4 mV/47 k≠ (PHONO MM)
Rated RCA Output Voltage and Impedance
0.2 V/2.3 k≠ (LINE OUT)
1 V/500 ≠ (SUBWOOFER PRE OUT)
Deviations from RIAA Equalizer
n0.5 dB (MM 20 Hz-20 kHz)
Phono Maximum Input Signal Voltage
70 mV (MM 1 kHz, 0.5%)
Frequency Response
10 Hz - 100 kHz/i1 dB, j3 dB (DIRECT)
Tone Control C haracteristics
n10 dB, 100 Hz (BASS)
n10 dB, 10 kHz (TREBLE)
Signal to Noise Ratio
106 dB (IHF-A, LINE IN, SP OUT)
81 dB (IHF-A, PHONO IN, SP OUT)
Speaker Impedance
4 ≠ - 16 ≠
Supported impedance of Headphones
8 ≠ - 600 ≠
Headphones Frequency Response
30 Hz -100 kHz
Power Supply
AC 220-230 V, 50/60 Hz
Power Consumption
150 W
0.2 W (Stand-by)
Dimensions (W k H k D)
435 mm k 129 mm k 330 mm
17-1/8" k 5-1/16" k 13"
Weight
8.0 kg (17.6 lbs)
Digital
OPTICAL (D2)
Maximum Fs: 192 kHz
COAXIAL (D1)
Maximum Fs: 192 kHz
Analog
PHONO, LINE1, LINE2, LINE3, LINE4, LINE5, MAIN IN
Analog
LINE OUT L/R
SUBWOOFER PRE OUT
Speaker Outputs
SPEAKERS : L/R
Phones
PHONE
S (Ø6.3 mm)
RI: 1
Amplifier (Audio) section
General
Audio Inputs
Audio Outputs
Others
SN29403409_A-9130_En_1806XX.book 23 ページ ２０１８年７月１２日 木曜日 午後８時４５分
