4
En
For British models
Replacement and mounting of an AC plug on the power
supply cord of this unit should be performed only by qual-
ified service personnel.
IMPORTANT
The wires in the mains lead are coloured in accordance
with the following code:
Blue: Neutral
Brown: Live
As the colours of the wires in the mains lead of this appa-
ratus may not correspond with the coloured markings
identifying the terminals in your plug, proceed as follows:
The wire which is coloured blue must be connected to the
terminal which is marked with the letter N or coloured
black.
The wire which is coloured brown must be connected to
the terminal which is marked with the letter L or coloured
red.
IMPORTANT
The plug is fitted with an appropriate fuse. If the fuse
needs to be replaced, the replacement fuse must approved
by ASTA or BSI to BS1362 and have the same ampere rat-
ing as that indicated on the plug. Check for the ASTA
mark or the BSI mark on the body of the fuse.
If the power cord’s plug is not suitable for your socket out-
lets, cut it off and fit a suitable plug. Fit a suitable fuse in
the plug.
For European Models
Supplied Accessories
Make sure you have the following accessories:
*
In catalogs and on packaging, the letter at the end of the prod-
uct name indicates the color. Specifications and operations are
the same regardless of color.
Installing the Batteries
Note
• If the remote controller
doesn’t work reliably, try
replacing the batteries.
• Don’t mix new and old
batteries or different
types of batteries.
• If you intend not to use
the remote controller for
a long time, remove the
batteries to prevent dam-
age from leakage or corrosion.
• Remove expired batteries as soon as possible to prevent damage
from leakage or corrosion.
Aiming the Remote Controller
To use the remote controller, point it at the AV receiver’s
remote control sensor, as shown below.
Declaration of Conformity
We,
ONKYO EUROPE
ELECTRONICS GmbH
LIEGNITZERSTRASSE 6,
82194 GROEBENZELL,
GERMANY
GROEBENZELL, GERMANY
ONKYO EUROPE ELECTRONICS GmbH
K. MIYAGI
declare in own responsibility, that the ONKYO product
described in this instruction manual is in compliance with the
corresponding technical standards such as EN60065,
EN55013, EN55020 and EN61000-3-2, -3-3.
Indoor FM antenna (➔ 21)
AM loop antenna (➔ 21)
Power cord (European, Australian and Asian models)
(➔ 21)
Speaker cable labels (➔ 13)
Speaker setup microphone (➔ 29)
Remote controller and two batteries (AA/R6)
(Note for China: The battery for the remote controller is not sup-
plied for this unit.)
Using the Remote Controller
Batteries (AA/R6)
Remote control sensor
AV receiver
Approx. 16 ft. (5 m)
