Onkyo TX-NR708 User Manual

62
En
Registering Presets
*1
Once you’ve added a station to the list, simply select it on
the Internet Radio screen, and then press ENTER to start
playback.
*1
From the search results you can preset the stations and songs
but cannot listen to them directly.
■ Items on the Internet Radio Top Menu
` Create new preset:
Add a favorite station or Internet Radio to the pre-
sets.
` Rename this preset:
You can rename the preset.
` Delete this preset:
This will delete the preset.
■ Station and Song Presets
You can add the currently playing song or station to the
presets.
1. Press MENU with the station selected or while a song
is playing.
2. Use q/w to select “Add this station to preset”, and
press ENTER.
This section explains how to play music files on a com-
puter or media server through the AV receiver. See “Sup-
ported Audio File Formats” to “About DLNA” for details
on supported music servers and music file formats.
For Windows Media Player 11, see “Windows Media
Player 11 Setup” (➔ 63).
Playing Music Files on a Server
NET/USB
DISPLAY
ENTER
q/w/e/r
RETURN
1, 3, 2, 5,
4, 7, 6
RANDOM
REPEAT
1
Start your computer or media server.
2
Press NET/USB to select the “Server” screen.
The NETWORK indicator lights (➔ 9).
Note
• When the NETWORK indicator flashes, confirm the net-
work connection.
• To update the screen, press RETURN.
3
Use q/w to select the “Server1”, and then press
ENTER.
A list of items on the server appears.
Search
You can search for music by Artist, Album, or Track.
Note
• The search function does not work with media servers
which do not support this function.
• Depending on the sharing settings in the media server, the
AV receiver may not able to access the content. Refer to
the instruction manual of the media server.
4
Use q/w to select an item, and then press ENTER.
A list of music files appears.
1 / 10
Server
Server1
Server2
Server3
Server4
Server5
Server6
Server7
Server8
Server9
Server10
1 / 8
Search
Recently Added
Artists
Album
Songs
Genre
Year
Rating
Server1
All Music
Song 1
1 / 10
Song 2
Song 3
My favorite song 1
My favorite song 2
My favorite song 3
My favorite song 4
My favorite song 5
My favorite song 6
My favorite song 7

Onkyo TX-NR708 Specifications

Power

power supply	AC 220–240 V~, 50/60 Hz
power consumption	570 W
dynamic power (3 Ω)	250 W
dynamic power (4 Ω)	220 W
dynamic power (8 Ω)	130 W

Amplifier Specifications

power output (front L/R)	170 W/Ch (6 Ω, 1 kHz, 1 channel driven, IEC)
power output (center)	170 W (6 Ω, 1 kHz, 1 channel driven, IEC)
power output (surround L/R)	170 W/Ch (6 Ω, 1 kHz, 1 channel driven, IEC)
thd (total harmonic distortion)	0.08% (Rated power)
damping factor	60 (Front, 1 kHz, 8 Ω)

Audio Specifications

input sensitivity and impedance (line)	200 mV/47 kΩ
input sensitivity and impedance (phono MM)	2.5 mV/47 kΩ
frequency response	5 Hz–100 kHz/+1 dB, -3 dB (DSP bypass)
tone control (bass)	±10 dB, 50 Hz
tone control (treble)	±10 dB, 20 kHz

Video Specifications

video input sensitivity/output level and impedance (component and S-Video Y)	1.0 Vp–p/75 Ω
video input sensitivity/output level and impedance (component PB/CB, PR/CR)	0.7 Vp–p/75 Ω
video input sensitivity/output level and impedance (S-Video C)	0.25 Vp–p/75 Ω
video input sensitivity/output level and impedance (composite)	1.0 Vp–p/75 Ω
component video frequency response	5 Hz–100 MHz/0 dB, -3 dB

Tuner Specifications

tuning frequency range (fm)	87.5 MHz–108 MHz
tuning frequency range (am)	522 kHz–1, 611 kHz
fm/am preset memory	40 stations

Weight and Dimensions

weight	12.5 kg
dimensions	435 x 175 x 379 mm
carton dimensions	570 x 298 x 469 mm
carton weight	16.5 kg
