Useful Information
Preparation
l
Preparethefollowingitems:

 RecoveryDisc(
USBmemorydevicecanalsobeusedasarecovery
disc.)
(

Reference Manual“CreateaRecoveryDisc”)

 Commerciallyavailableopticaldrive
l
Removeallperipherals andSDmemorycardetc.(exceptforthecommerciallyavailable
opticaldrive).
l
ConnecttheACadaptoranddonotremoveituntilinstallationiscomplete.
1 Connect the commercially available optical drive to the USB port.
2 Start the Setup Utility.
A
 Click
(Start)-[Settings]-[Update&security]-[Recovery].
B
 Click[Restartnow]under“Advancedstartup”.
C
 Click[Troubleshoot]-[Advancedoptions]-[UEFIFirmwareSettings]-[Restart].
Turnonthecomputer,andpress
F2
or
Del
while[Panasonic]bootscreenisdisplayed.
l
Ifthe[Panasonic]bootscreenisnotdisplayed,turnonthecomputerwhileholdingdown
F2
or
Del
.
l
Ifthepasswordisrequested,entertheSupervisorPassword.
3 Write down all of the contents of the Setup Utility and press
F9
.
Attheconrmationmessage,select[Yes]andpress
Enter
.
4 Check the [UEFI Boot] setting of the Setup Utility.
[UEFIBoot]shouldbesettoasfollows.
WhentherecoverydiscforWindows10isused :[Enabled]
WhentherecoverydiscforWindows7isused :[Disabled]
5 Set the Recovery Disc into the DVD drive or commercially available
optical drive.
6 Press
F10
.
Attheconrmationmessage,select[Yes]andpress
Enter
.
Computerwillrestart.
7 Press
F2
or
Del
while [Panasonic] boot screen is displayed.
TheSetupUtilitystartsup.
l
Ifthepasswordisrequested,entertheSupervisorPassword.
8 Select the [Exit] menu, then select DVD drive or commercially avail-
able optical drive in [Boot Override] and press
Enter
.
Thecomputerwillrestart.
9 Click [Recovery].
10
Click [Reinstall Windows] and click [Next].
11
At the conrmation message, click [YES].
12
At the License Agreement screen, click [Yes, I agree to the provisions
above and wish to continue!] and click [Next].
13
Click [Disk 0].

Panasonic CF-20 Specifications

General

Category	Laptop
Storage	256GB SSD
Operating System	Windows 10 Pro
Model	CF-20
Processor	Intel Core m5-6Y57 vPro
RAM	8GB
Display	10.1" WUXGA 1920 x 1200
Rugged Features	MIL-STD-810G, IP65
Graphics	Intel HD Graphics 515
Bluetooth	Bluetooth v4.1
Ports (Tablet)	USB 3.0, HDMI, MicroSDXC
Ports (Keyboard Dock)	USB 3.0, HDMI, VGA, Ethernet
Camera	8MP rear camera with autofocus and LED light
Dimensions	10.7 x 9.2 x 1.3 inches
Ports	USB 3.0, HDMI, Audio Out, MicroSDXC, SIM (Tablet); USB 2.0 x2, USB 3.0, LAN, Serial, HDMI, VGA, SDXC (Keyboard Dock)
