Panasonic KX-NS500 User Manual

Paging and then Transferring a Call
Announce.
Talk.
On-hook.
During a conversation
Cellular Phone
Enter 33.
Wait for an
answer.
The held party and the paged extension
are connected and start a conversation.
The party is placed on hold.
Dial paging group
number (2 digits).
paging group
no.
33
C.Tone
D.Tone
Enter #.
268 User Manual
1.15.1 Cellular Phone Features

Panasonic KX-NS500 Specifications

General

Analog Extensions	Up to 64
VoIP Support	Yes
System Type	Hybrid IP-PBX
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	0°C to 40°C
Humidity	10% to 90% (non-condensing)
Maximum Extensions	288
IP Extensions	128
VoIP Channels	64
SIP Trunks	64
Networking	Yes, supports networking
Built-in Applications	Call Center
Expandability	Yes, via expansion cards and cabinets
Supported Protocols	SIP, H.323, MGCP
Dimensions	430 x 88 x 367 mm
