Panasonic KX-NS500 User Manual

To record a prompt
Select a Prompt No., and click Play/Record.
When "Record from extension" is selected:
a. Specify the
extension number of the telephone used
for recording, then click Connect.
b. When the specified extension rings, go off-hook.
c. Click Record, Stop, or Play to record or play a
system prompt.
d. Click Disconnect.
When "Import from recorded file" is selected:
a. Click Browse. The Open dialogue box appears.
b. Navigate to the folder containing the WAV files you
wish to import.
c. Select the desired WAV file.
d. Click Open to import the file.
e. Click OK.
To start and stop prompt playback
a. Select the desired prompt.
b. Click Play/Record.
c. Click Play or Stop.
To delete a specific prompt
a. Select the desired prompt.
b. Click Delete.
c. Click OK.
Customising your mailbox setting
You can change your mailbox setting in the Unified Message tab of the Edit User screen.
1. In the Unified Message tab, click Advanced setting.
2. The Mailbox Settings box appears.
The following items are editable.
330 User Manual
3.2.1 User Programming

Panasonic KX-NS500 Specifications

General

Analog Extensions	Up to 64
VoIP Support	Yes
System Type	Hybrid IP-PBX
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	0°C to 40°C
Humidity	10% to 90% (non-condensing)
Maximum Extensions	288
IP Extensions	128
VoIP Channels	64
SIP Trunks	64
Networking	Yes, supports networking
Built-in Applications	Call Center
Expandability	Yes, via expansion cards and cabinets
Supported Protocols	SIP, H.323, MGCP
Dimensions	430 x 88 x 367 mm
