Panasonic KX-NS500 User Manual

When setting the features or programming
Confirmation Tones
Tone 1
• The feature setting was set
successfully.
• A call
is received in Voice-calling
mode.
1 s
Tone 2
• Before
receiving
a page through
an external speaker
• You receive a call in Hands-free
mode.
• You established a call with a
KX-UT series SIP phone that
has Hands-free Answerback
enabled.
1 s
Tone 3
• Before the following features
activate:
• Retrieving a held call
• Picking up another call
• Paging/Answering a paging
announcement
• Answering
the
call through a
speaker
• You establish a call with an
extension in the following cases:
• The called extension has
hands-free Answerback
enabled and is not a KX-UT
series SIP phone.
• Voice-calling mode
• When making a call to or from a
doorphone.
1 s
Tone 4
Establishing or
leaving a conference
1 s
Tone 5
A call has been put on hold.
1 s
392 User Manual
5.4.1 What is This Tone?

Panasonic KX-NS500 Specifications

General

Analog Extensions	Up to 64
VoIP Support	Yes
System Type	Hybrid IP-PBX
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	0°C to 40°C
Humidity	10% to 90% (non-condensing)
Maximum Extensions	288
IP Extensions	128
VoIP Channels	64
SIP Trunks	64
Networking	Yes, supports networking
Built-in Applications	Call Center
Expandability	Yes, via expansion cards and cabinets
Supported Protocols	SIP, H.323, MGCP
Dimensions	430 x 88 x 367 mm
