18.9 Flash Management
The Peplink Balance 210 and 310 are equipped with dual flash memory modules. The Peplink Balance
380, 390, 580, 710 and 1350 have single module but with two partitions. Each flash memory or partition
stores one firmware image. It does not only allow improved flexibility but also facilitates more effective
management of the flash contents. It is possible to upgrade the firmware on the module/partition that is
not designated for booting, so that the boot flash is unaffected by firmware upgrade process or any
potential power failures throughout.
Flash module management is located at: System > Flash Management
For Peplink Balance 210 and 310:
For Peplink Balance 380, 390, 580, 710 and 1350:
Flash Management
Firmware Version
This displays the firmware version on each flash module/partition
(i.e. Flash 1 or Flash 2)
Flash Status
This shows the status of the flash module.
Boot from…
The star indicates the flash module/partition from which Peplink Balance will perform its
next boot.
Next Firmware
Upgrade Target
The star indicates the flash module that is the target of the next firmware upgrade.
By default, the target of the next firmware upgrade is the flash module that is NOT
designated for the next boot.
For Peplink Balance 210, and 310, by clicking Load config from Flash X, the configuration parameters
on the corresponding flash module will be loaded but not applied. (X corresponds to the flash module
that is NOT designated for the next boot.) For example, clicking Load config from Flash 1 loads the
configuration from Flash 1, but does not apply the corresponding settings.
The configuration parameters are applied upon clicking the Reboot button at System > Reboot.
