170
Safety
Summary table of the locations for i-Size child seats
The i-Size child seats have two latches that engage on the two rings A.
The i-Size child seats also have:
- either an upper strap which is attached to the ring B,
- or a support leg resting on the vehicle floor, compatible with the approved i-Size seat,
the role of which is to prevent the child seat from tipping forward in the event of a collision.
For more information on ISOFIX mountings, refer to the corresponding section.
In accordance with the new European regulations, this table indicates the options for installing i-Size child seats on seats in the vehicle fitted with
ISOFIX mountings approved for i-Size.
Seating position Passenger's front airbag i-Size restraint system
Row 1 (a) Passenger seat
Deactivated "OFF" Not i-Size
Activated "ON" Not i-Size
Row 2
Seat behind driver's seat i-U
Seat behind the front passenger's
seat
i-U
Centre rear seat i-U
