Pfaff 3371-1 series Adjustment Manual

Adjustment
14 - 13
14.14 Position of the thread wiper
Requirement
When the thread wiper is centred to the needle, its lower edge should be 14 – 15 mm
above the upper edge of the needle plate.
● Bring the thread wiper 1 into the appropriate position by operating the work clamp
manually.
● Move thread wiper 1 (screw 2) in accordance with the requirement.
Fig. 14 - 10
14 - 15 mm
2
1
