Philips DVDR615 Service Manual

Technical Specifications and Connection Facilities
EN 3DVDR615/69 1.
Frequency response: : 0.1- 4.00 MHz ± 3dB
Group delay ( 0.1 MHz - 4.4 MHz ) : 0 nsec ± 150nsec
1.4.6 Audio Performance:
Audio Performance Analogue - HiFi:
Frequency response at Cinch Out
(L+R) output: : 100 Hz - 12 kHz / 0±
3dB
S/N according to DIN 45405, 7, 1967 :
and PHILIPS standard test pattern
video signal: : ≥ 50dB, unweighted
Harmonic distortion ( 1 kHz, ± 25
kHz deviation ): : ≤ 1.5%
Audio Performance NICAM:
Frequency response at Cinch Out
(L+R) output: : 40 Hz - 15 kHz 0 ±
3dB
S/N according to DIN 45405, 7, 1967 :
and PHILIPS standard test pattern
video signal: : ≥ 60 dB unweighted
Harmonic distortion (1 kHz): : ≤ 0.5 %
1.4.7 Tuning
Automatic Search Tuning
scanning time without antenna : typ. 3 min.
stop level (vision carrier) : ≥ 37dBµV
Maximum tuning error of a recalled
program : ± 62.5 kHz
Maximum tuning error during
operation : ± 100 kHz
Tuning Principle
automatic B,G, I and DK detection
manual selection in "STORE" mode
1.5 Analogue Inputs / Outputs
1.5.1 External 1
Component Video Cinch Y/Pb/Pr
according to EIO-770-1-A, EIA-770-2-A
Audio - Cinch
Input voltage : 1Vpp ± 3dB
Input impedance : >10kΩ
1.5.2 External 2
Audio- Cinch
Output voltage : 2Vrms max.
Output impedance : >10kΩ
Video- Cinch
Output voltage : 1 Vpp ± 3dB
Output impedance : 75 Ω
Video - YC (Hosiden)
According to IEC 933-5
Superimposed DC-level on pin 4 (load > 100kΩ)
< 2.4V is detected as 4:3 aspect ratio
> 3.5V is detected as 16:9 aspect ratio
Input voltage Y :1Vpp ± 3dB
Input impedance Y :75 Ω
Input voltage C :burst 300 mVpp ± 3 dB
Input impedance C :75 Ω
1.5.3 Audio/Video Front Input Connectors
Audio - Cinch
Input voltage : 2.2 Vrms
Input impedance : >10kΩ
Video - Cinch
Input voltage : 1 Vpp ± 3dB
Input impedance : 75 Ω
Video - YC (Hosiden)
According to IEC 933-5
Superimposed DC-level on pin 4 (load > 100kΩ)
< 2.4V is detected as 4:3 aspect ratio
> 3.5V is detected as 16:9 aspect ratio
Input voltage Y : 1Vpp ± 3dB
Input impedance Y : 75 Ω
Input voltage C : burst 300 mVpp ± 3
dB
Input impedance C : 75 Ω
1.5.4 Out 1
Component Video Cinch Y/Pb/Pr
according EIO-770-1-A, EIA-770-2-A
Audio- Cinch
Output voltage : 2Vrms max.
Output impedance : >10kΩ
1.5.5 Out 2
Audio- Cinch
Output voltage : 2Vrms max.
Output impedance : >10kΩ
Video- Cinch
Output voltage : 1 Vpp ± 3dB
Output impedance : 75 Ω
Video - YC (Hosiden)
According to IEC 933-5
Superimposed DC-level on pin 4 (load > 100kohm)
< 2.4V is detected as 4:3 aspect ratio
> 3.5V is detected as 16:9 aspect ratio
Output voltage Y : 1Vpp +10/-15%
Output voltage C : 300mVpp +1/-4dB
1.6 Video Performance
All outputs loaded with 75 Ohm
SNR measurements over full bandwidth without weighting.
1.6.1 SCART (RGB)
SNR : > 48 dB
Bandwidth : 4.8 MHz − 3dB
1.7 Audio Performance CD
1.7.1 Cinch Output Rear
Output voltage 2 channel mode : 2Vrms ± 1dB
Channel unbalance (1kHz) : <0.22dB
Crosstalk 1kHz : >100dB
Crosstalk 16Hz-20kHz : >87dB
Frequency response : ±0.2dB max
Signal to noise ratio : >85 dB
Dynamic range 1kHz : >83dB
Distortion and noise 1kHz : >83dB
http://www.jdwxzlw.com/?fromuser=华盛维修
家电维修资料网，免费下载各种维修资料

Philips DVDR615 Specifications

Picture/Display

Aspect ratio	4:3, 16:9
D/A converter	10 bit, 54 MHz
A/D converter	10 bit, 54 MHz

Sound

D/A converter	24 bit, 96 kHz
A/D converter	24 bit, 96 kHz
Signal to noise ratio	90
Distortion and Noise (1kHz)	83 dB
Crosstalk (1kHz)	105 dB
Dynamic Range (1kHz)	83 dB

Power

Power supply	110V, 60Hz
Power consumption	27 W
Standby power consumption	< 4 W

Dimensions

Set dimensions (W x H x D)	435 x 285 x 65 mm
Set weight	3.5 kg
Packaging dimensions (W x H x D)	518 x 159 x 383 mm
Weight incl. Packaging	5.5 kg
