PIAGGIO MP3 300 User Manual

02_04
Shock absorbers adjustment (02_04)
The preloading of the springs can be adjusted to 4 positions acting on the ring nut
located in the lower part of the shock absorbers with the specific spanner supplied.
Position 1: minimum preload: rider only
Position 2 medium preloading: rider only
Position 3 medium preloading: rider and passenger
Position 4: maximum preloading: rider, passenger, and luggage.
In order to carry out this operation you will need to use the specific spanner in the kit.
CAUTION
RIDING THE VEHICLE WITH THE SPRING PRELOADING NOT CORRECTLY SET
FOR THE RIDER AND POSSIBLE PASSENGER, COULD REDUCE THE COM-
FORT OF THE RIDE AND THE PRECISION OF THE STEERING.
WARNING
WE RECOMMEND WEARING GLOVES WHILE CARRYING OUT THIS OPERA-
TION IN ORDER TO AVOID INJURIES.
WARNING
IT IS ABSOLUTELY FORBIDDEN TO ADJUST THE PRELOAD DIFFERENTLY ON
THE TWO SHOCK ABSORBERS
32
2 Use

PIAGGIO MP3 300 Specifications

General

Engine Type	Single-cylinder, 4-stroke
Displacement	278 cc
Fuel System	Electronic fuel injection
Transmission	Automatic CVT
Rear Brake	240 mm disc
Seat Height	780 mm
Dry Weight	225 kg
Cooling System	Liquid-cooled
Front Suspension	Articulated quadrilateral
Front Brake	Two 258 mm discs
Fuel Tank Capacity	11 liters
Front Tire	110/70-13
Rear Tire	140/60-14
Rear Suspension	Dual hydraulic shock absorbers
