PIAGGIO MP3 300 User Manual

03_02
Engine oil top-up
Always check the oil level before topping up, and add oil without exceeding the
MAX level. Getting an oil level between the MIN and MAX levels requires ~ 400 cm³
of oil. Take your vehicle to an Authorised Service Centre to have the oil checked
and if necessary, topped-up as indicated in the scheduled maintenance table.
03_03
Warning light (insufficient oil pressure) (03_03)
The vehicle is equipped with a warning light that comes on when the key is turned to
«ON». However, this light should come off once the engine has been started. If the
light comes on while braking, at idle speed or while turning a corner, it is nec-
essary to check the oil level and top it up if required. If after having topped-up
the oil, the warning light still comes on while braking, at idle speed or while
turning a corner, it will be necessary to take your vehicle to an Authorised Serv-
ice Centre.
47
3 Maintenance

PIAGGIO MP3 300 Specifications

General

Engine Type	Single-cylinder, 4-stroke
Displacement	278 cc
Fuel System	Electronic fuel injection
Transmission	Automatic CVT
Rear Brake	240 mm disc
Seat Height	780 mm
Dry Weight	225 kg
Cooling System	Liquid-cooled
Front Suspension	Articulated quadrilateral
Front Brake	Two 258 mm discs
Fuel Tank Capacity	11 liters
Front Tire	110/70-13
Rear Tire	140/60-14
Rear Suspension	Dual hydraulic shock absorbers
