PIAGGIO MP3 300 User Manual

Brake fluid
FMVSS DOT 4 Synthetic fluid
03_25
03_26
Battery (03_25, 03_26)
To access the battery, proceed as follows:
1. Place the scooter on its centre stand;
2. Open the saddle, following the previously described procedure;
3. Remove the tool kit cover
4. Remove the three fasteners "A" and the cover "B".
WARNING
IN ORDER TO AVOID DAMAGING THE ELECTRICAL SYSTEM, NEVER DISCON-
NECT THE WIRING WHILE THE ENGINE IS RUNNING.
60
3 Maintenance

PIAGGIO MP3 300 Specifications

General

Engine Type	Single-cylinder, 4-stroke
Displacement	278 cc
Fuel System	Electronic fuel injection
Transmission	Automatic CVT
Rear Brake	240 mm disc
Seat Height	780 mm
Dry Weight	225 kg
Cooling System	Liquid-cooled
Front Suspension	Articulated quadrilateral
Front Brake	Two 258 mm discs
Fuel Tank Capacity	11 liters
Front Tire	110/70-13
Rear Tire	140/60-14
Rear Suspension	Dual hydraulic shock absorbers
