03_29
03_30
03_31
Fuses (03_29, 03_30, 03_31)
The electrical system is equipped with eleven fuses to protect the different circuits,
subdivided into two fuse boxes «A» and «B», located inside the battery compartment.
The chart shows the position and specifications of the fuses in the vehicle.
CAUTION
BEFORE REPLACING A BLOWN FUSE, FIND AND SOLVE THE FAILURE THAT
CAUSED IT TO BLOW. NEVER TRY TO REPLACE THE FUSE WITH ANY OTHER
MATERIAL (E.G., A PIECE OF ELECTRIC WIRE).
62
