02_11
02_12
Front suspension locking system (02_11, 02_12, 02_13, 02_14,
02_15, 02_16, 02_17)
The front suspension locking system simply prevents, where available, vehicle tilting
when the «T » switch is pressed. With this device, the vehicle can be stopped without
your feet touching the ground.
The warning light «E» starts flashing when the ignition switch is set to «ON». This
means that the system is enabled for locking activation.
When the «T» switch is turned to «1 » a continuous sound alarm signals that the
locking system is engaged and, at the same time, the warning light «E» turns on
steadily.
When the «T switch is turned to «2» an intermittent sound alarm signals that the lock-
ing system is disengaged and, at the same time, the warning light «E » starts flashing
again. Warning light «E » turns off when riding starts. This means that the system
allows for vehicle tilting.
(N.B.: if the rider is not seated on the saddle, to carry out the system unlocking press
the switch «T» twice).
Engaging roll lock is possible only if the following conditions occur at the same time:
Throttle completely untwisted.
Engine rpm below 2,500 rpm
Vehicle speed below 10 km/h.
Locking system WARNING light «Q » off (the system has not detected fail-
ures)
If one of these conditions is not checked, the warning light «E » remains off and locking
cannot be engaged (in normal riding conditions, the warning light «E» is off).
With engine on, system locked and warning light «E» on, the suspension locking sys-
tem is disengaged automatically and the warning light «E » turns off when the throttle
is twisted to start the ride.
For riders' safety, the vehicle has a
rider detection sensor in the saddle which ena-
bles the system to prevent vehicle motion and suspension unlocking (in case of locked
40
2 Use

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the PIAGGIO MP3 300 and is the answer not in the manual?

PIAGGIO MP3 300 Specifications

General IconGeneral
Engine TypeSingle-cylinder, 4-stroke
Displacement278 cc
Fuel SystemElectronic fuel injection
TransmissionAutomatic CVT
Rear Brake240 mm disc
Seat Height780 mm
Dry Weight225 kg
Cooling SystemLiquid-cooled
Front SuspensionArticulated quadrilateral
Front BrakeTwo 258 mm discs
Fuel Tank Capacity11 liters
Front Tire110/70-13
Rear Tire140/60-14
Rear SuspensionDual hydraulic shock absorbers
