03_41
N.B.
THE ABOVE PROCEDURE COMPLIES WITH THE EUROPEAN STANDARDS RE-
GARDING MAXIMUM AND MINIMUM HEIGHT OF LIGHT BEAMS. REFER TO THE
STATUTORY REGULATIONS IN FORCE IN EVERY COUNTRY WHERE THE VE-
HICLE IS USED.
Front direction indicators (03_42, 03_43)
- Remove the top fairing and the headlamp surround.
For the removal procedure, refer to the paragraph regarding the Front Headlight
Assembly.
03_42
- Remove the two fixing screws "C" and detach the turn indicator.
70
