Refitting
- Insert the components making sure to thoroughly
grease the O-ring and the oil seal.
- Follow the steps in reverse order taking care to
tighten to torque.
WARNING
IN ORDER TO PREVENT ABNORMAL FORMATIONS OF
DIRT DUE TO THE RELEASE OF GREASE, WE RECOM-
MEND FIRST LUBRICATING THE SEAL RING STOPS WITH
A BRUSH.
Locking torques (N*m)
Crankcase timing cover screws 3.5 ÷ 4.5
Oil pump
Removal
- Remove the flywheel.
- Preventing rotation, unscrew the water pump
command screw and collect the washer.
CAUTION
THE THREAD IS ANTICLOCKWISE.
MP3 400 hpe E5 Engine
ENG - 115
