Intermediate gear
- Remove the flywheel.
- Remove the intermediate gear from its housing.
- Visually inspect the surfaces, if there is no abnormal wear, grease the housing thoroughly and insert
the intermediate gear.
Refitting the free wheel
- Make sure the freewheel contact surfaces are in good condition.
- Thoroughly clean the free wheel to remove LOCTITE residue.
- Degrease the threading of the holes in the free wheel and the clamping screws.
- Apply the recommended product to the end of the screws.
Recommended products
Loctite 243 Medium strength thread-locking sealant.
Blue
- Fit the freewheel on the magneto flywheel making
sure that the ground side is in contact with the fly-
wheel itself, i.e. with wheel Seeger ring visible.
- Lock the six clamping screws in criss-cross fash-
ion to the prescribed torque.
Locking torques (N*m)
Screw fixing freewheel to flywheel 13 - 15
- Oil the free wheel "rollers".
Engine MP3 400 hpe E5
ENG - 82
