Flywheel and starting
Removing the starter motor
- Undo the two fixing screws and remove the start-
er motor.
Removing the flywheel magneto
- Undo the screw indicated and remove the plate.
- Install the support plate.
Specific tooling
020916Y Magneto flywheel blocking tool
Engine MP3 400 hpe E5
ENG - 80
