Removing the clutch
- To remove the clutch assembly it is necessary to
remove the inlet pinion to the final reduction unit,
operating as described in the section «Dismount-
ing the hub cover».
- Working from the automatic transmission side,
remove the driven pulley.
- Unscrew the six fixing screws from the clutch
cover.
- By using two screwdrivers work on the appendi-
ces and remove the cover taking care not to drop
the clutch assembly.
- Remove the clutch assembly.
Engine MP3 400 hpe E5
ENG - 42
