- Remove the gasket.
Removing the valves
- Use the specific tool to remove the cotters, cap
and spring.
CAUTION
PROPERLY REPLACE THE PADS AND ROCKERS SO AS
TO PRESERVE THE COUPLINGS.
Specific tooling
020382Y Tool to extract valve cotters
020382Y012 bush (valve removing tool)
MP3 400 hpe E5 Engine
ENG - 91
