- Insert the Belleville spring facing upwards, taking
care to insert it properly into the seat in the closure
ring.
- Fit the specific tool to compress the clutch pack
and place the retaining ring at the specified loca-
tion.
Specific tooling
020919Y Clutch discs disassembly tool
FINAL CHECK
Once the clutch is assembled, turn by hand the exit axis to the final reduction.
The rotation must be free.
If you feel resistance in the movement, or if you detect impediments, disassemble the clutch again and
check the correct installation.
Engine MP3 400 hpe E5
ENG - 54
