Specification Desc./Quantity
Rear tire Tubeless 140/70 - 14" 68S
Front tyre pressure 2 bar
Rear tire pressure (with passenger) 2.4 (2.6) bar
Kerb weight 257 kg
Maximum weight limit 460 kg
Battery 12V - 12Ah
Engine Data
ENGINE SPECIFICATIONS
Specification Desc./Quantity
Type Single cylinder 4-stroke
Engine capacity 399 cc
Bore per stroke 84,0 x 72,0 mm
Compression ratio 11,5 ± 0,5 :1
Idle speed 1600 ± 100 rpm
Timing system Four valves, single overhead camshaft, chain-driven.
Valve clearance Intake: 0.10 mm
Exhaust: 0.15 mm
Maximum power 26.0 kW at 7000 rpm
Maximum torque 37.7 Nm at 5500 rpm
Transmission With the expandable pulley continuously variable transmission
with torque server, trapezoid belt, automatic clutch oil bath
centrifuge.
Final drive reduction gear Gear reduction unit in oil bath.
Lubrication Engine lubrication with trochoidal pump (inside the crankcase),
oil filter and pressure adjustment by-pass.
Cooling Forced coolant circulation system.
Starting Electric
Ignition Electronic, inductive, high efficiency ignition, integrated with the
injection system, with variable advance and separate H.V. coil.
Ignition advance Three-dimensional map managed by control unit
Power supply Indirect electronic injection.
Spark plug NGK / MR7BI-8
Fuel Unleaded gasoline E10 (95 R.O.N.)
Silencer Absorption-type exhaust silencer with a three-way catalytic
converter and lambda probe to the exhaust.
Emissions compliance EURO 5
Capacities
CAPACITY
Specification Desc./Quantity
Engine oil 1.40 l
Transmission oil 500 cm³
Cooling system liquid - replacement ~ 1.8 l
Fuel tank 13.2 ± 0.5 l
MP3 400 hpe E5 Technical Data
DT - 19
