Indicator list
Area 1 Area 2
Area 3
Area 1
Indicates that the selected fre-
quency is being broadcast in
stereo.
Indicates that a Bluetooth tele-
phone is connected.
Indicates that the digital format is
Dolby Digital.
Indicates that the digital format is
MPEG Audio.
Indicates that the digital format is
Linear PCM.
Indicates the sampling frequency.
Indicates that the digital format is
DTS.
1+1ch
2
ch
Mch
Indicates the audio channel.
Indicates that a disc with PBC On
is being played.
! Indicates that a cellular phone
is connected.
! Indicates that an incoming call
has been received and has not
been checked yet.
! Not displayed for calls made
when your cellular phone is
disconnected from this unit.
Indicates the battery strength of
the cellular phone.
! The level shown on the indica-
tor may differ from the actual
battery strength.
! If the battery strength is not
available, nothing is displayed
in the battery strength indica-
tor area.
Indicates the signal strength of the
cellular phone.
Indicates that Auto EQ is on.
Shows when HD Radio signal is re-
ceived.
Shows when analog audio of HD
Radio signal is received.
Shows when digital audio of HD
Radio signal is received.
Shows when HD Radio station in-
formation is received.
Shows when downloadable song
information (tag) from a radio sta-
tion is received.
Shows when song information
(tag) from an HD Radio station is
being saved to this unit.
Shows while searching a song/
video in alphabet search mode.
Shows when song information
(tag) is being saved to your iPod.
Shows when this unit has the song
information (tag).
Shows which audio language has
been selected.
<QRB3126-A/N>93
En
93
Appendix
Additional Information
Additional Information
