Additional information
Windows 7
Windows and the Windows logo are trademarks of the Microsoft group of companies.
MHL
MHL, the MHL Logo, and Mobile High-Definition Link are trademarks or registered trademarks of MHL, LLC in the
United States and other countries.
Auto Surround, ALC and Stream Direct with different input signal
formats
The following charts show what you will hear with different input signal formats, depending on the Stream Direct
mode (see Using Stream Direct on page 60) you have selected.
Stereo (2 channel) signal formats
Input signal format
Auto Surround / ALC /
DIRECT
PURE DIRECT
Surround Back speaker(s): Connected
Dolby Digital Surround
2 Pro Logic IIx MOVIE 2 Pro Logic IIx MOVIE
DTS Surround
Neo:X CINEMA Neo:X CINEMA
Other stereo sources Stereo playback Stereo playback
Analog sources As above ANALOG DIRECT (stereo)
PCM sources As above Stereo playback
DVD-A sources As above As above
SACD sources As above As above
Surround Back speaker(s): Not connected
Dolby Digital Surround
2 Pro Logic II MOVIE 2 Pro Logic II MOVIE
DTS Surround
Neo:X CINEMA Neo:X CINEMA
Other stereo sources Stereo playback Stereo playback
Analog sources As above ANALOG DIRECT (stereo)
PCM sources As above Stereo playback
DVD-A sources As above As above
SACD sources As above As above
Multichannel signal formats
Input signal format Auto Surround / ALC PURE DIRECT / DIRECT
Surround Back speaker(s): Connected
Dolby Digital EX (6.1 channel flagged)
Dolby TrueHD EX (6.1 channel flagged)
Dolby Digital EX
2 Pro Logic IIx MOVIE
<a>
Dolby Digital EX
2 Pro Logic IIx MOVIE
<a>
DTS-HD Master Audio ES (6.1 channel flagged) DTS-ES (Matrix) DTS-ES (Matrix)
DTS-ES (6.1 channel sources/6.1 channel flagged) DTS-ES (Matrix/Discrete) DTS-ES (Matrix/Discrete)
DTS sources (5.1 channel encoding) Straight decoding Straight decoding
DTS-HD sources As above As above
Other 5.1/6.1/7.1 channel sources As above As above
Surround Back speaker(s): Not connected
DVD-A sources/Multi-ch PCM Straight decoding Straight decoding
SACD sources (5.1 channel encoding) As above As above
Other 5.1/6.1/7.1 channel sources As above As above
a Unavailable with only one surround back speaker connected.

Pioneer sc-lx86 Specifications

General

Receiver type	Surround
Output impedance	6 Ω
Speaker selector	A+B
Audio output channels	9.1 channels
Total Harmonic Distortion (THD)	1 %
Power output per channel (1KHz@6 Ohm)	190 W
Power output per channel (20-20KHz@8 Ohm)	- W
HDMI in	8
AC (power) in	Yes
Remote (IR) input	1
Composite video in	4
Digital audio optical in	2
Multichannel audio input type	RCA
Component video (YPbPr/YCbCr) in	3
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Supported radio bands	AM, FM
Optical drive included	No
Display	-
Product color	Black
Audio decoders	Dolby Digital, Dolby Digital Plus, Dolby Pro Logic, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS, DTS 96/24, DTS-ES, DTS-HD, DTS-HD Master Audio
Apple docking compatibility	iPad, iPhone, iPod
On Screen Display (OSD) languages	DEU, DUT, ENG, ESP, FRE, ITA, RUS
Graphical user interface (GUI) language	English, French, German, Italian, Russian, Spanish
AC input voltage	230-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	370 W
THX-certified	THX Select2 Plus
Cables included	AC
