Flow of settings on the receiver
Flow for connecting and setting the receiver
The unit is a full-fledged AV receiver equipped with an abundance of functions and terminals. It can be used eas-
ily after following the procedure below to make the connections and settings.
Required setting item: 1, 2, 3, 4, 5, 7, 9
Setting to be made as necessary: 6, 8, 10, 11, 12, 13
Important
The receiver’s initial settings can be made on the computer using Wiring Navi on the AVNavigator CD-ROM
included with the receiver. In this case, virtually the same connections and settings as in steps 2, 3, 4, 5, 6, 7
and 8 can be made interactively. For instructions on using AVNavigator, see About using AVNavigator (included
CD-ROM) on page 9.
1 Before you start
! Checking what’s in the box on page 7
! Loading the batteries on page 8
j
2 Determining the speakers’ application (page 19)
! [A] 9.2 channel surround system (Front height/Front wide) connection
! [B] 7.2 channel surround system & Speaker B connection
! [C] 7.2 channel surround system & Front Bi-amping connection (High quality surround)
! [D] 7.2 channel surround system (Surround back) & ZONE 2 connection (Multi Zone)
! [E] 7.2 channel surround system (Front height/Front wide) & ZONE 2 connection (Multi Zone)
! [F] 5.2 channel surround system & Front Bi-amping connection (High quality surround) & ZONE 2 connection
(Multi Zone)
! [G] 5.2 channel surround system & ZONE 2/ZONE 3 connection (Multi Zone)
! [H] 5.2 channel surround system & Speaker B Bi-amping connection
! [I] 5.2 channel surround system & Front and Surround Bi-amping connection (High quality surround)
! [J] 5.2 channel surround system & Front and Center Bi-amping connection (High quality surround)
j
3 Connecting the speakers
! Placing the speakers on page 22
! Connecting the speakers on page 22
! Installing your speaker system on page 24
! Bi-amping your speakers on page 23
j
4 Connecting the components
! About the audio connection on page 29
! About the video converter on page 29
! Connecting your TV and playback components on page 30
! Connecting AM/FM antennas on page 36
! Plugging in the receiver on page 43
j
5 Power On
j
6 Making the initial settings according to the region and environment in which you live
! Changing the OSD display language (OSD Language) (page 45)
! Changing the TV format setting (page 45)
! Changing the frequency step (page 45)
j
7 MCACC speaker settings
! Automatically conducting optimum sound tuning (Full Auto MCACC) on page 45
j
8 The Input Setup menu (page 47)
(When using connections other than the recommended connections)
j
9 Basic playback (page 49)
j
10 Switching the HDMI output (page 79)
j
11 Adjusting the sound and picture quality as desired
! Using the various listening modes (page 57)
! Better sound using Phase Control (page 61)
! Better sound using Phase Control and Full Band Phase Control (page 61)
! Measuring the all EQ type (SYMMETRY/ALL CH ADJ/FRONT ALIGN) (page 89)
! Changing the channel level while listening (page 98)
! Switching on/off the Acoustic Calibration EQ, Auto Sound Retriever or Dialog Enhancement (page 73)
! Setting the PQLS function (page 70)
! Setting the Audio options (page 73)
! Setting the Video options (page 75)
j
12 Other optional adjustments and settings
! Control with HDMI function (page 68)
! The Advanced MCACC menu (page 88)
! The System Setup and Other Setup menus (page 96)
j
13 Making maximum use of the remote control
! Operating multiple receivers (page 82)
! Setting the remote to control other components (page 82)
