Pioneer SC-LX88 User Manual

112
Using Safari to update the firmware
1 Launch Safari on your computer.
2 Press Bookmark icon. Click Bonjour list (a), and then select this receiver’s name
(Friendly Name) (b) in Bookmark.
If Bonjour list is not displayed, access the IP address“http://(the receiver’s IP address)” from Safari.
3 On the AVNavigator menu screen, select Network Setup.
4 Click Firmware Update.
5 Press Start.
The firmware update prepare screen is displayed. If the screen does not switch automatically, click Click here.
6 Browse the latest firmware on your computer (a) and then press Upload (b).
Firmware files have the extension “fw”. Select a file with the extension “fw”.
The confirmation screen is displayed. If you continue the firmware update, press OK. Once the firmware update
process starts, you cannot stop it. Wait until the file is uploaded (about one minute may be required depending
on your LAN connection environment).
a
b
7 The firmware upload status screen is displayed.
“The upload process finished successfully.” will be shown when the update is completed.
Once updating is completed, the receiver’s power automatically turns off.
Note
This setting for the network has been confirmed for Mac OS X 10.7 and Safari 5.1.
The System Setup and Other Setup menus
12

Pioneer SC-LX88 Specifications

General

Receiver type	Surround
Speaker selector	A+B
Input sensitivity	400 mV
4Ω speaker support	Yes
Audio output channels	9.2 channels
Audio A/D Converter (ADC)	24-bit/192kHz
Signal-to-Noise Ratio (SNR)	103 dB
Total Harmonic Distortion (THD)	1 %
Power output per channel (1KHz@6 Ohm)	220 W
Power output per channel (20-20KHz@8 Ohm)	- W
HDMI in	8
USB ports quantity	3
Ethernet LAN (RJ-45) ports	1
Component video (YPbPr/YCbCr) in	2
Multichannel audio output type	Terminals
Speakers connectivity type	-
Audio formats supported	AAC, AIFF, FLAC, M4A, MP3, WAV, WMA
Supported radio bands	AM, FM
Preset stations quantity	63
Optical drive included	No
Supported video modes	1080i, 1080p, 480p, 720p
Product color	Black
Audio decoders	Dolby Digital, Dolby Digital Plus, Dolby TrueHD, DTS, DTS Neo:X, DTS-ES, DTS-HD Master Audio
Volume control	Rotary
Apple docking compatibility	Not supported
On Screen Display (OSD) languages	DEU, DUT, ENG, ESP, FRE, ITA, RUS
AC input voltage	220-230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	370 W

Weight and Dimensions

Depth	441 mm
Width	435 mm
Height	185 mm
Weight	15300 g
