38
Connecting your equipment
03
Connecting other audio components
This receiver has both digital and analog inputs, allowing you to connect audio components for playback.
When you set up the receiver you’ll need to tell the receiver which input you connected the component to (see
also The Input Setup menu on page 52 ).
LAN
(
10/100
)
DC OUTPUT
for WIRELESS LAN
(
OUTPUT 5 V
0.6 A MAX
)
(
OUTPUT 5 V
0.9 A MAX
)
OPTICALCOAXIAL
ASSIGNABLE ASSIGNABLE
AUDIO
L
R
IN
1
(
CD
)
PHONO
IN
IN
1
(
DVD
)
BD IN
IN
2
(
SAT/CBL
)
IN
3
(
DVR/BDR
)
IN
6
IN
4
IN
7
/MHL
IN
1
(
TV
)
IN
2
(
DVR/BDR
)
IN
1
(
DVD
)
IN
2
(
SAT/CBL
)
OUT
SIGNAL
GND
OUT 3
(HDZONE)
OUT 2OUT 1
(CONTROL)
SELECTABLE
HDMI
ASSIGNABLE
1
-
7
ASSIGN-
ABLE
LAN
(
10/100
)
DC OUTPUT
for WIRELESS LAN
(
OUTPUT 5 V
0.6 A MAX
)
(
OUTPUT 5 V
0.9 A MAX
)
OPTICALCOAXIAL
ASSIGNABLE ASSIGNABLE
AUDIO
L
R
IN
1
(
CD
)
PHONO
IN
IN
1
(
DVD
)
BD IN
IN
2
(
SAT/CBL
)
IN
3
(
DVR/BDR
)
IN
6
IN
4
IN
7
/MHL
IN
1
(
TV
)
IN
2
(
DVR/BDR
)
IN
1
(
DVD
)
IN
2
(
SAT/CBL
)
OUT
SIGNAL
GND
OUT 3
(HDZONE)
OUT 2OUT 1
(CONTROL)
SELECTABLE
HDMI
ASSIGNABLE
1
-
7
ASSIGN-
ABLE
CD player, MD, DAT, etc.
DIGITAL OUT
COAXIAL
ANALOG
RL
AUDIO OUT
OPTICAL
Select one
DIGITAL IN
OPTICAL
Turntable
! If your turntable has line-level outputs (i.e., it has a built-in phono pre-amp), connect it to the ANALOG IN 1
(CD) inputs instead.
! You can’t hear HDMI audio through this receiver’s digital out jack.
Connecting additional amplifiers
This receiver has more than enough power for any home use, but it’s possible to add additional amplifiers to every
channel of your system using the pre-outs. Make the connections shown below to add amplifiers to power your
speakers.
PRE OUT
SURROUND SURR BACK
T.MIDDLE
(Single)
FRONT CENTER
SUBWOOFER
1
2
F WIDE
PRE OUT
SURROUND SURR BACK
T.MIDDLE
(Single)
FRONT CENTER
SUBWOOFER
1
2
F WIDE
R
L
ANALOG
INPUT
R
L
ANALOG
INPUT
R
L
ANALOG
INPUT
ANALOG
INPUT
ANALOG
INPUT
R
L
ANALOG
INPUT
Front channel
amplifier
Center channel
amplifier (mono)
Surround
channel amplifier
Top middle
channel amplifier
Surround back
channel amplifier
Powered
subwoofer 2
ANALOG
INPUT
Powered
subwoofer 1
R
L
ANALOG
INPUT
Front wide
channel amplifier
! If you’re not using a subwoofer, change the front speaker setting (see Speaker Setting on page 100 ) to
LARGE.
! You can use the additional amplifier on the surround back channel pre-outs for a single speaker as well. In this
case plug the amplifier into the left (SURROUND BACK L (Single)) terminal only.
! The sound from the surround back terminals will depend on how you have configured the Speaker system set-
ting on page 103 .
! If you have two subwoofers, the second subwoofer can be connected to the SUBWOOFER 2 terminal.
Connecting two subwoofers increases the bass sound to achieve more powerful sound reproduction.
! To hear sound only from the pre-outs, switch the speaker terminals to SP: OFF (page 83 ) or simply discon-
nect any speakers that are connected directly to the receiver.
It is also possible to hear sound only from the pre-outs by switching the AMP setting to OFF and setting the
pre-amp mode to turn the power amplifiers for all channels off (see Setting the Audio options on page 79 ).
