Pioneer SC-LX88 User Manual

49
Basic Setup
04
How to use the built-in AVNavigator
The built-in AVNavigator is equipped with Wiring Navi, which allows you to perform connection of this receiver
and initial settings in interactive mode. By simply following the screen prompts to connect and set the unit, highly
accurate initial settings can be performed easily.
Additionally, in order to use various functions easily, contents linked to the receiver can be used.
Operating Environment
! AVNavigator can be used in the following environments.
— Windows PC: Microsoft
®
Windows
®
XP/Windows Vista
®
/Windows
®
7/Windows
®
8/Windows
®
8.1
— Mac: Mac OS X (10.7, 10.8 or 10.9)
— iPad/iPhone/iPod touch: iOS 7
— Android device: Android 4.0.4, 4.1.1, 4.1.2, 4.2, 4.2.2, 4.4.2
! AVNavigator uses an Internet browser. The following browsers are supported:
— Windows PC: Internet Explorer
®
8, 9, 10, 11
— Mac/iPad/iPhone/iPod touch: Safari 6.0
— Android device: Android browser
! Depending on the computer network setting or security setting, AVNavigator may not operate.
Using AVNavigator
Important
! Connect the LAN terminal to the network (page 43 ).
1 Press u STANDBY/ON to switch on the receiver and your computer.
2 Launch AVNavigator.
Operate AVNavigator by following the screen prompts of your computer, etc.
! If using a Windows PC, complete the below steps to start up.
1 Start up Internet Explorer on your PC (open any random Internet page).
2 Press STATUS on the remote control and check the front panel display on the receiver (the IP address of
the receiver will appear).
(Example Text Display)
If 0.0.0.0 or 169.254.112.202 appears in the address, it indicates that the receiver is not connected to the
network. Check to make sure that the receiver and router are properly connected.
3 Enter number in 2 above in the field in Internet Explorer shown below and then press the ENTER key.
(Example Input Format) 192.168.0.124
! With a Windows PC other than Windows XP, you can use the following method to launch AVNavigator.
Launch Explorer and right-click <SC-LX88> or <SC-LX78> displayed in the ‘Network’ folder, then click
‘View device webpage’.
! On a Mac, launch Safari and click <SC-LX88> or <SC-LX78> displayed in ‘Bonjour’ on the Bookmarks bar.
— If ‘Bonjour’ is not displayed, tick the ‘Include Bonjour in the Favorites bar’ check box on the
‘Advanced’ tab in the Safari ‘Preferences...’ menu.

Pioneer SC-LX88 Specifications

General

Receiver type	Surround
Speaker selector	A+B
Input sensitivity	400 mV
4Ω speaker support	Yes
Audio output channels	9.2 channels
Audio A/D Converter (ADC)	24-bit/192kHz
Signal-to-Noise Ratio (SNR)	103 dB
Total Harmonic Distortion (THD)	1 %
Power output per channel (1KHz@6 Ohm)	220 W
Power output per channel (20-20KHz@8 Ohm)	- W
HDMI in	8
USB ports quantity	3
Ethernet LAN (RJ-45) ports	1
Component video (YPbPr/YCbCr) in	2
Multichannel audio output type	Terminals
Speakers connectivity type	-
Audio formats supported	AAC, AIFF, FLAC, M4A, MP3, WAV, WMA
Supported radio bands	AM, FM
Preset stations quantity	63
Optical drive included	No
Supported video modes	1080i, 1080p, 480p, 720p
Product color	Black
Audio decoders	Dolby Digital, Dolby Digital Plus, Dolby TrueHD, DTS, DTS Neo:X, DTS-ES, DTS-HD Master Audio
Volume control	Rotary
Apple docking compatibility	Not supported
On Screen Display (OSD) languages	DEU, DUT, ENG, ESP, FRE, ITA, RUS
AC input voltage	220-230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	370 W

Weight and Dimensions

Depth	441 mm
Width	435 mm
Height	185 mm
Weight	15300 g
