3.2.4 ROLLER MOTOR (M4) AND PRESSURE ROLLER
Changing of wear point
ThewearpointistheareaontherollerthatstrikestheBookletrst,astheroller
moves from the home position (left and right).
1. Remove outfeed cover (
3.1.4).
2. Move Roller Motor Assembly towards center of clamps.
3. StopPressureRollerfrommovingbypressingwithyourngerstowardsthe
Pressure Roller and out from the Clamps.
4. Move Roll Motor Assembly 20 to 30 mm’s (1”) sideways.
MOTORS
M4
